Dual Press Control KP15 LP:Auto HP:Manual Capillary & Brkt - 60000766

Dual Press Control KP15 LP:Auto HP:Manual Capillary & Brkt

Part Number: 60000766

Dual Press Control KP15 LP:Auto HP:Manual Capillary & Brkt

Part Number: 60000766
Danfoss

Sign in to your Aire-Biz account to view pricing and stock levels.

Sign in

Not an Airefrig customer? Complete our online account application form here to apply for a credit account.

  • Product Description

    KP PRESSURE SWITCHES

    KP pressure switches are designed to protect refrigeration systems from:
    - excessively high discharge pressures
    - excessively low suction pressures
    - start / stop compressors
    - operate air-cooled condenser fans

    The enhanced contact system for 16A makes it possible to operate electrical motors up to 2 kW directly, without the use of contactors.
    KP pressure switches are available in IP30 and IP44 enclosures.
    Versions of the KP series are available for applications with HCFC and non-flammable HFC refrigerants, ammonia and hydrocarbons.

    Refrigerants:
    All HCFC and non-flammable HFC refrigerants

    Benefits:
    High reliability both electrically and mechanically-a KP switch can be connected directly to a single-phase AC motor of up to approximately 2 kW or installed in the control circuit of DC motors and large AC motors.
    Versions with IP30 enclosure rating can be updated to IP44 or IP55 enclosure rating using top cover (IP44) or IP55 enclosure (IP55) available as accessories.
